Anbai AT516 AT516L Ohmímetro
- Descripción
- Consulta
Descripción
Ohmmeter
Breve introducción
AT516/AT516L is brand-new design DC resistance meter with high precision and high stability, which adopts high-performance 32dgt ARM micro processor control. 3.5 inches true-color LCD display screen with Chinese and English menu, and it is easy to operate. AT516/AT516L can be applied to various kinds of resistors, switches contact resistance, connector contact resistance, relay coils and contact resistance, transformadores, inductores, motores, deflecting coiling resistance, welding contact conductor resistance, the metal riveting resistance of vehicles, boats, airplanes, printed circuit lines and crack detection and so on.
Ohmmeter
|
ESPECIFICACIONES |
||||
| AT516 DC Resistance Meter | AT516L DC Resistance Meter | |||
| Parámetros |
Resistencia a DC |
|||
| Precisión básica |
0.05% |
0.1% | ||
| Rango de medicion | 1metroW.~20MW | 1mW~30kW | ||
| Measurement Current | I-max:<1A | I-max:<1A | ||
| Rango |
Automatic and Manual with 10 rangos |
7 Automatic or Manual |
||
| Velocidad |
140 t/s, 67 t/s,35 t/s,12 t/s, 2 t/s |
12 veces/segundo,2 veces/segundo |
||
| Mostrar |
Show/ΔABS/Δ%/Sorting Results |
|||
| Pantalla máx. |
30,000 |
|||
| Ajustamiento |
Short-circuit Zero-Adjust for each range. |
|||
| Comparador |
14 build-in comparators, BIN1-BIN10, HI/IN/LOW display and output, adjustable beep and volume |
1 grupo |
||
| Desencadenar |
Nivel, Interno, Manual, External and Remote Trigger |
Interno ,Manual, Remote |
||
| Interfaz | RS-232C, Manipulador (interfaz PLC), interfaz USB | RS-232C interface, interfaz USB | ||
| Test Lead | 4 terminal shielding (2 check terminal and 2 driving terminal) and external shielding ground section | |||
| Temperature compensation | Exactitud: 0.2 °C
Rango: 0~80 °C |
|||
| Otros | True-color TFT-LCD display
Keypad locks function; Data Hold function; Menú chino e inglés. |
|||
|
CARACTERÍSTICAS GENERALES |
||||
| Fuente de alimentación |
Voltaje: 198VAC~240VAC, Frecuencia: 50/60Hz; Max Power: 15Virginia. Opcional: 110VACACIONES |
|||
| Tamaño |
Afuera (milímetros):264 (ancho)x107(altura)x350 (profundidad) Inside (milímetros):216(ancho)x88(altura)x323(profundidad), 4kg |
|||
| ORDER ING INFORMATION | ||||
| Accesorio | ATL501A Kelvin clip; ATL108: 232 cable de comunicacion; temperature compensation probe; Cable de alimentación de CA | |||
| Opciones | ATL620 Meter Resistance Four-terminal Clamp Fixture | |||
