2. Material: 304/316L stainless steel, Hastelloy C276

3. Design pressure: 22MPa

4. Design temperature: 350℃

2. Stirring speed: 0-1000 rpm

3. Motor power: 150W

4. Stirring form: magnetic coupling stirring

5. Heating method: električno ogrevanje (sandwich oil bath heating)

6. Heating power: 2 KW

7. Natančnost nadzora temperature: ±1 ℃

2. Temperature control (program control can be customized)

3. Temperature display

4. Speed ​​display

5. Two-compartment electricity (220V)

2. The gas phase port is equipped with a needle valve (equipped with an air inlet pipe to meet the connection of various applicable gases such as hydrogen, nitrogen, and oxygen)

3. The vent port is equipped with a needle valve

4. The liquid phase port is equipped with a needle valve with a bottom tube inserted in the kettle (for sampling or upper discharge)

5. The pressure safety explosion-proof port is equipped with a pressure gauge and a bursting valve (explosion-proof disk)

6. The temperature measuring port is equipped with a protective tube with a platinum resistor

7. The cooling coil in the kettle is removable (can be equipped with a plug)

8. With insulation layer

9. Manual lifting of kettle cover (can be changed to electric lifting)

2. Air inlet: ∅4

3. Vent port: ∅4

4. Cooling water inlet and outlet: ∅4

5. Temperature measuring port: ∅4

6. Pressure gauge port: ∅4

2. Lifting rod

3. Controller

4. Air inlet pipe

5. Instructions and precautions

6. Sealing and vulnerable parts

7. Kilogram wrench

(4-7 should be installed in the controller carton)

2.Packaging weight: 151kg
