LT2200E Wet Laser Particle Analysis Device

Features:

The LT2200E laser particle size meter is equipped with patented polarization filtering technology, which eliminates the traditional pinhole and mechanical adjustment, and realizes the highly stable laser polarization setting and spatial filtering. The use of the first diffraction Airy spot anomalous change (ACAD) compensation correction technology allows users to obtain accurate and reliable particle size results over the full particle size range without selecting an analysis mode.



LT2200E Wet Laser Particle Analysis Device

Benefit Technology:
◆ Polarization filtering technology *
◆ Compensation and correction technology of anomalous change of diffraction Airy spot (ACAD)
◆ Oblique incidence inverse Fourier path configuration
◆ Grille type large Angle detection array technology
◆ Particle size analysis model optimization and adaptive technology
◆ Continuous liquid level sensing and control technology
◆ High sensitivity light energy tracking and stabilization technology



LT2200E Wet Laser Particle Analysis Device

Performance also includes:
◆ Fully in line with ISO13320 diffraction measurement technical standards
◆ Unique optical path configuration, large continuous physical measurement Angle
◆ Improved inversion algorithm, users do not need to choose “analysis mode”, taking into account extremely high resolution and stability
◆ No need to replace the lens, no need to use standard sample calibration, measuring range of 0.1 micron to 1200 micron
◆ Holographic signal synchronous processing technology, real-time measurement speed of up to 20,000 times per second, does not miss any shape and distribution of particles diffraction information
◆ The ultra-stable solid laser light source system with automatic temperature constant technology completely overcomes the disadvantages of long preheating time and short service life of He-ne gas laser
◆ The polarization space filter technology is used to completely abandon the pinhole filter that leads to poor mechanical and thermal stability



LT2200E Wet Laser Particle Analysis Device

Parameter

detecting system It includes a grille detector array with large Angle, non-uniform cross area compensation and a high sensitivity backscatter detection unit
sampling method ** Wet dispersed sampling system: Support SOP one-click operation measurement, compatible with organic and aqueous dispersion media, sample pool capacity of up to 1000 ml, liquid level continuously adjustable. Sample mixing and circulation dual motor design and independent control, speed 0-2500RPM continuously adjustable. Built-in high-power probe type ultrasonic dispersion system, the dispersion power is continuously adjustable, and supports automatic bubble elimination technology. (Optional Hydrolink injection system)
** Dry dispersed sampling system: Support SOP one-click operation measurement, dispersion pressure 0-4.5Bar continuous adjustable, airflow pressure control accuracy ±0.1Bar (optional Aerolink injection system)
light source 638nm solid-state laser with integrated thermostatic system, up to 20mW
Spatial filtering mode Non-pinhole polarization filter patented technology
measuring cell Parallel slant
Optical alignment system Intelligent fully automatic
measuring speed Up to 20,000 times per second
measuring time Typical values are less than 10 seconds
degree of accuracy Dv50 better than ±0.6% (NIST-Traceable latex standard)
repeatability Dv50 better than ±0.5% (NIST-Traceable latex standard)
laser safety Class 1 laser products
computer configuration Intel i5 processor, 4GB RAM, 250GB hard drive, mouse, keyboard and widescreen display
computer interface USB2.0 or above
Software running platform Windows7 or above Professional Edition
operating ambient temperature 5ºC-40ºC
Operating ambient humidity 10%-85% relative humidity (no condensation)
power requirement Ac 220V, 50Hz-60Hz, standard ground
Optical system weight 30KG
Optical system size 670mm x 275mm x 320mm
