Description

GA-MN60L Stone Gloss Meter

Product introduction
MN60 mirror gloss meter is a small portable machine, its technical parameters conform to the national standard GB9754-88, GB9966.5 and international standard ISO2813. each
All the performance indicators meet the requirements of national JJG696-2002 (Calibration Regulation of mirror gloss meter).

This product is suitable for marble, granite, terrazzo and other architectural decoration materials surface glossiness measurement.



GA-MN60L Stone Gloss Meter

Instrument features:
1. The ultra-small design can be put in the pocket, more convenient to carry, is the current domestic small volume, light weight gloss meter.
2. Ultra-power-saving design, using a No. 5 battery (rechargeable battery or alkaline battery can be used), you can operate. A new battery can last up to 60 hours
Above, about 10,000 data can be measured.
3. Special moisture-proof process allows you to rest assured that it can be used in a variety of harsh environments.
4. Immediately open and test, no waiting time, stable value, no drift, easy to quickly measure.
5. Long life light source, no need to replace.



GA-MN60L Stone Gloss Meter

Note:
1. Avoid direct light during use, otherwise the measurement accuracy will be affected.
2. The standard board of the instrument should be kept clean. Do not touch the surface with your fingers. If the surface is stained, it will lead to increased instrument error and inaccurate reading
Wipe with head paper or anhydrous ethanol.
3. Because of the high stability of the instrument, the instrument does not need to be calibrated frequently, it is recommended to re-calibrate once after continuous use for 2 hours.
4, the battery should be replaced in time, otherwise long-term storage, the old battery may flow out of waste liquid, causing damage to the instrument.



GA-MN60L Stone Gloss Meter

Parameter

measuring range 0~199Gs(Gloss unit)
stability less than ±1 Gs/30Min
indication error less than ±2Gs
zero deviation With automatic zero stabilization function, no need to adjust zero
working power supply One 5 (AA) alkaline battery or rechargeable battery
working voltage 0.8V~1.5V
Projection Angle 60°
Measuring port size 14x28mm
service conditions environment temperature:0℃~40℃
Relative humidity: not more than 85%
Main engine size (L)114mm x (W)32mm x (H)64mm
Standard board box size (L)67mm×(W)46mm×(H)13mm
Main engine weight 180g
Standard box weight 45g
