GA-F216 Asphalt high temperature rotational viscometer
I. Product Introduction

The Asphalt High Temperature Rotational Viscometer is designed and manufactured in accordance with the requirements of T 0625-2011, “Asphalt Rotational Viscosity Test (Brookfield Viscometer Method)” in the Transportation Industry Standard JTG E20-2011, “Test Procedures for Asphalt and Asphalt Mixtures for Highway Engineering,” of the People’s Republic of China. It is suitable for measuring the absolute viscosity of Newtonian liquids and the apparent viscosity of non-Newtonian liquids. It is widely used for measuring the viscosity of various fluids, including asphalt, hot melt adhesives, paraffin wax, and polymers.

GA-F216 Asphalt high temperature rotational viscometer
II. Operating Environment

Ambient Temperature: 5°C-35°C (Recommended operating temperature: 20°C-25°C)
Relative Humidity: ≤80%
The product must be kept free of strong electromagnetic interference, severe vibration, and corrosive gases.

GA-F216 Asphalt high temperature rotational viscometer
III. Main Technical Parameters:
Measuring range 10mPa.s–200,000mPa.s
Measuring error ≤ ±3 (full scale)
Random rotor Four spindles available: 21, 27, 28, and 29
Display information Viscosity value, temperature, torque, speed, and spindle number
Speed Seven selectable speeds: 0.5, 1, 2, 5, 10, 20, and 50
Temperature range Rate range: Room temperature to 250°C
Temperature accuracy 0.1°C
Interface RS232C
Sample container capacity 20 mL
Power supply AC 220V 50Hz
Dimensions 95*130*155 (excluding base)
Net weight 2 kg (excluding base)
