BEICH CH2801 Single Channel Digital Power Meters

Descrizione

Power Meters

introduzione al prodotto:
CH2800 Power meter is the newly-developed smart type, it adopts the latest theory with the super anti interference ability to keep the accuracy and consistency of test. The power meter is widely used in the energy consumption test for household appliances, power consumption of lighting and LED, motore, charger and switch power test.

Power Meters

Caratteristiche principali:
1.High Definition 4.3 inch TFT color display
2.USB interface for data recording and firmware update, optional Wifi router for remote checking in PC or client in cell phone Voltage, attuale, power waveform and harmonic waveform display
2.MAX hold function for obtaining peak value
3.Min test current 0.05 mA,power 0.001W,for micro power test like standby power consumption(CH2806)
4.All test value is Trms
5.Auto range, precisione: 0.5 classes
6.Simple and fast setting for high and low limit warning function, support data lock
7.Super anti interference ability
8.Standard RS232C and USB Device communication interface
9.Standard rack size, adopting soft rubber material in front and rear panel, beautiful and anti-skidding

Power Meters
