NS810 Portable Spectrophotometer

Gebruik

NS810 portable spectrophotometer uses d/8 structure and comply with CIE No.15, GB/T 3978. With 400~700nm, NS810 features with high accuracy DeltaE*ab 0.04, and 8mm aperture makes measurement so easy. It can save 1000 Standaarde, 15000 Samples and you also can input your own LAB or XYZ value into the instrument. With SQC8 software, you can do better color control management. Plus, it is widely used in plastic, elektronies, verf, ink, tekstiel, garment, druk en kleur, kos, medical, cosmetic, industries, scientific research institutes, schools and laboratories.

NS810 Portable Spectrophotometer

Kenmerke:

  1. Display complete reflectance rate and input LAB value manually.
  2. NS810:D/8 structure (diffuse illumination, 8° besigtiging )
  3. 3.5 inch large capacitive touch screen, fully functional touch control.
  4. 2º/10º degree observe, multiple lights, many color systems.
  5. The repeatability ΔE*ab is within 0.04, errors is less than 0.2
  6. Large capacity storage, meer as 15000 data.
  7. PC software with powerful extension functions.
  8. 15° oblique angle screen, in line with the human eye observation.
  9. Oversized integrating sphere, more effective homogenization ray of lights.
  10. High hardware configuration with a number of innovative technologies.



NS810 Portable Spectrophotometer

Spesifikasie

Model NS810 Spectrophotometer
Illumination/observation system d/8 (diffuse beligting, 8-degree viewing angle) Conforms to CIE No.15, GB/T 3978.
Integrating sphere Size Φ58mm
Ligbron Combined LED sources
Sensor Silicon photodiode array
Wavelength range 400~700nm
Wavelength pitch 10nm
Reflectance range 0~200%
Meet diafragma Φ8mm
Color Space CIE LAB, XYZ, Yxy, LCh, CIE LUV,LAB&WI&DOEN
Color difference Formula ΔE*ab,ΔE*uv,ΔE*94,ΔE*cmc(2:1),ΔE*cmc(1:1),ΔE*cmc(l:c),CIE2000ΔE*00,ΔE(h)
Other Chromaticity Data WI(ASTM E313,CIE/ISO,AATCC, Jagter),

DOEN(ASTM D1925,ASTM 313),

Metamerism Index (Mt), Color Strength

Color Stain, Kleurvastheid
Observer 2°/10°
Illuminant D65,D50,A,C,D55,D75,F1,F2,F3,F4,F5,F6,F7,F8,F9,F10,F11,F12
Display Data Spectral Value/Graph, Colorimetric Value, Color Difference Value/Graph, PASS/FAIL Result, Color Offset, Color Simulation, color index setting(ΔE*94, ΔE*cmc, ΔE2000), tolerance prompt, reverse prompt, time setting, language setting, restore factory setting
Measurement Time 1.5s
Herhaalbaarheid Spectral Reflectance: standard deviation within 0.1%(400~700nm: within 0.2%)
Colorimetric Value: Standard deviation within DeltaE*ab 0.04 (Measurement conditions: white calibration plate measured 30 times at 5 seconds intervals after white calibration was performed.)
Inter Instrument Agreement Within DeltaE*ab 0.2 (Average for 12 BCRA Series II color tiles)
Dimensie L*W*H=90*77*230mm
Gewig 600g
Battery Li-ion battery. 2800 times within 8 ure.
Lamp Life 5 jare, meer as 1.6 million measurements
Display Screen TFT 3.5inch, Capacitive Touch Screen
Koppelvlak USB/RS-232
Data Memory 1000 Standaarde, 15000 Samples
Operating Temperature 0~40℃(32~104°F)
Storage temperature -20~50℃(-4~122°F)
Standard Accessory Kragadapter, Li-ion Battery, Operating Instruction, CD-ROM (containing management software), Data Line, White and Black Calibration Cavity, Protective Cover and Wrist Strap
Optional Accessory Universal Test Components, Micro Printer, Powder Test Box
Notes The specifications are subject to change without notice.



NS810 Portable Spectrophotometer

Aansoeke:

It is widely used in plastic, elektronies, verf, ink, tekstiel, garment, druk en kleur, kos, medical, cosmetic industries, scientific research institutes, schools and laboratories. It can measure reflectance spectrum and other color index precisely. NS810 spectrophotometer not only can help to perform color matching and color management studies, but also can control product quality management. 3nh colorimeter is equipped with high-end color management software that can connect to PC to achieve more extension functions.
