GA-3649 Pendulum Impact Testing Machine

Sự miêu tả

GA-3649 Pendulum Impact Testing Machine

Ứng dụng

Pendulum impact is suitable for the determination of impact toughness of hard plastics, reinforced nylon, glass steel, gốm sứ, cast stone, electrical insulation materials and other non-metallic materials. In testing all kinds of hard

GA-3649 Pendulum Impact Testing Machine

Giới thiệu

After the test piece of rubber material is hit by a certain Angle and a certain weight, the energy can be absorbed to determine the toughness of the material.
This machine is a testing instrument with simple structure, beautiful shape, convenient operation and accurate data. Display mode is divided into, pointer dial display. Products comply with ISO179,
180, GB/T1043, 1843, ASTM D256, JB8762, JB8761, ISO9854, GB18743 and other standards.
The pendulum impact testing machine conforms to the international standard ISO180-1992 “Plastic-hard material cantilever beam impact strength determination”; National standard GB/ T1843-1996 “Hard.
Plastic cantilever beam impact test method, mechanical industry standard JB/ T8761-1998 “Plastic cantilever beam impact testing machine”.

GA-3649 Pendulum Impact Testing Machine

Các thông số kỹ thuật chính:
1. Dung tích :30,50,150KG-CM
2. Impact speed :3.5M/SET(11T/SEC)
3. Pendulum energy: 2.75J, 5.5J, 11J
4. Test Angle :150°
5. Blade radius: R=0.8±0.2mm
6. The distance from the blade to the top of the jaws: 22±0.2mm
7. Impact blade Angle: 37°±l°
8. Âm lượng: about 550X400X690mm
9. Cân nặng: about 50kg
