GA-Y103 Eyeglass Lens Abrasion Tester

Описание

Внедрение продукции

This automatic counting reciprocating friction tester, designed in accordance with the Light Industry Standards of the People’s Republic of China for the abrasion resistance of optical resin lenses and the friction resistance test method for coated lenses, primarily tests the surface quality of lenses. The lens surface is rubbed with steel wool or a pencil according to relevant standards to determine its abrasion resistance.

Стандарты

ГБ 10810.5-2012 Spectacle Lenses. Часть 5: Requirements for Lens Surface Abrasion Resistance
QB 2506-2001 Optical Resin Spectacle Lenses;
QB 2506-2001;
КБ/Т 2702-2005
DIN EN ISO 8980-5-2005 Ophthalmic Optics. Finished Uncut Spectacle Lenses. Часть 5: Requirements for Surface Abrasion Resistance of Spectacle Lenses
ИСО 8980-5-2005 Ophthalmic Optics. Finished Uncut Spectacle Lenses. Часть 5: Requirements for Surface Abrasion Resistance of Spectacle Lenses

Experimental

Test Procedure: Использовать 000# steel wool to rub the lens at a reciprocating frequency of 100 раз/мин, an amplitude of 10°, a swing radius of 103±0.87mm, and a total load of 750g. Rub 1000 times to test the lens’ abrasion resistance.
Test Requirements: Haze value after abrasion should be no greater than 2.5%. For lenses marked as hardened, the haze value after testing should be no greater than 0.8%.

Технические параметры

Система контроля: ПЛК;
User Interface: 7-дюймовый цветной сенсорный экран, китайский и английский;
Steel Wool: 000# steel wool;
Mold: φ40mm;
Friction Frequency: 100 раз/мин (регулируемый);
Test Distance: 0-150мм (регулируемый);
Масса: Нержавеющая сталь, 750 ± 15g;
Размеры: 560 × 540 × 570mm;
Масса: 26кг;
Источник питания: 220 В переменного тока, 50 Гц
