Analizor de infraroșu apropiat GA-6132 NIR
Prezentare generală:
1.A capable NIR analyzer suitable for different industriesand applications
GA-6132 is a highly versatile near-infrared spectrometer capable of analysing various sample forms (granular, solid, pudra, pastă, lichid, etc) with it versatile design and accessories. It is suitable for typical applications from agriculture and industry, such as farming, grain, food processing, animal feed, petrochemical and many other sectors.
2.Rich calibration library for various applications
GA-6132 provides a rich library of standard calibration for various app- lications, including different types of cereal, rapeseed, soybean, sunflower etc. The device has a wide infrared wavelength range of 950-1650nm, which enables more applications and higher accuracy.
3.Easy-to-use touchscreen and online support
The user interface is based on a 7-inch touchscreen which makes it easy for daily operations. It requires minimal training to end users for daily operation. Online support is available when the device is connected to the Internet to perform software upgrade or remote diagnosis.
Analizor de infraroșu apropiat GA-6132 NIR
Parametrii
| Interval de lungime de undă (NIR) | 950-1650nm | |
| Detector | InGaAs detector | |
| Spectrophotometry | Array MEMS microscope + raster | |
| Baseline noise | ≤0.0005A | |
| Wavelength repeatability | ≤0.05nm | |
| Wavelength accuracy | ≤2nm,with
monitorig |
built-in automatic |
| Absorbance repeatability | ≤0.0005AU | |
| Time measured | ≤1min | |
| Light source | Halogen tungsten lamp | |
| Dimensiuni L:265mm/W;340.5mm/H;262.3mm
Weight 9Kg
Built-in operating system Linux |
||||||||
| Operating/storage temperature | 5-45 ℃/-20-60 ℃
<RH75% |
|||||||
| Relative humidity | ||||||||
