CH8811 Power Supply Charging Machine
- Descriere
- Anchetă
Descriere
CH8811 Power Supply Charging Machine
Introducerea Produsului:
CH8800 series medium power programmable DC electronic load series can be widely used in power transformer, charger, switching power supply, storage battery and other industries online testing and laboratory testing fields. More power selection to meet the needs of users with higher power.
The series of instruments use large character LCD display to display clearly and intuitively, and the operation is more simple and convenient. Its perfect functions of constant voltage, constant current, constant power, constant resistance, remote measurement, short circuit test, battery test, dynamic test and upper computer software control enable you to get a multi-purpose, affordable and convenient.
Caracteristici principale:
■ Large-character backlight LED display with clear and comprehensive display
■ More power configurations to meet higher user needs
■ CC, CV, CR, CP, Dynamics, List, Battery Discharge Mode
■ 1mV/1mA High Precision and High Resolution
■ Perfect multiple overload protection
CH8811 Power Supply Charging Machine
Indicatori tehnici majori:
| Model Parametru |
CH8811 | CH8812 | CH8813 | CH8811A | CH8812A | CH8813A |
| Modul de testare | Fixed Voltage,Fixed Current,Fixed Power, Fixed Resistance | |||||
| Modul de afișare | 20*2LCD’s clear and direct display with backlight | |||||
| Maximum input voltage | 120V | 360V | ||||
| Maximum input current | 60A/120A | 60A | ||||
| Maximum input power | 600W | 900W | 1200W | 600W | 900W | 1200W |
| Voltage accuracy | 0.1%+0.03%FS | |||||
| Current accuracy | 0-6A/12A :±0.1%+0.1%FS 0-60A/120A:±0.2%+0.15%FS |
0-12A :±0.1%+0.1%FS 0-120A:±0.2%+0.15%FS |
||||
| Minimum analysis | Voltage 1mV Current 1mA | |||||
| List test function | Tensiune nominală,Curent nominal,Putere nominală Rezistenta nominala,SCURT,DESCHIDE |
|||||
| Battery test function | Intrare:2-120V/360V Max measurement capacity:999A/H Timer range:1~60000sec |
|||||
| Dynamic measurement function | Range of Frequency 0.1Hz-1KHz | |||||
| Remote measurement function | Available | |||||
| Standard RS232C interface | Available | |||||
| Protection mode | Over-voltage,Over-current,Over-power, Over-temperature,Opposite polarity |
|||||
| Temperatura de lucru & humidity | 0℃~40℃,≤90%RH | |||||
| Cerința de putere | 198-242VAC 99V-121VAC 47.5-63Hz | |||||
| Consumul de energie | ≤40VA | |||||
