Model:GA-FZ103

Category:

Description

GA-FZ103 Double Compression Airflow Method Cotton Fiber Fineness/Maturity Tester
Scope of Application:

The double compression airflow method cotton fiber fineness/maturity tester is suitable for measuring indicators such as micronaire value, linear density (metric count), and maturity (including maturity ratio, percentage of mature fibers, and can be converted into maturity coefficient using empirical formulas) of cotton fibers.

GA-FZ103 Double Compression Airflow Method Cotton Fiber Fineness/Maturity Tester
Relevant Standards:

The instrument complies with the requirements of GB/T 13778 “Cotton Fiber Maturity Test Method – Airflow Method”, ISO 10360 “Textiles – Cotton Fibers – Determination of Maturity (Airflow Method)”, ASTM 3818 “Standard Test Method for Cotton Fiber Density and Maturity Index”, BS 3181 “Method for the Determination of Cotton Fibre Fineness – Airflow Method”, and other standards. It is suitable for various types of cotton and cotton varieties, including short-staple cotton, long-staple cotton, and coarse cotton.

GA-FZ103 Double Compression Airflow Method Cotton Fiber Fineness/Maturity Tester
Main Technical Specifications:
Project Measurement range: Accuracy
Micronaire value 2.0–8.0 ±0.1
Linear density 350–100 ±7.0mtex
Maturity ratio 0.6–1.2 ±0.1
Percentage of mature fibers 40–100 ±5.0%

GA-FZ103 Double Compression Airflow Method Cotton Fiber Fineness/Maturity Tester

Instrument Component Parameters:

a. Rotameter: Upper scale value 4 L/min, Lower scale value 1 L/min
b. Liquid manometer: Reading accuracy 5 Pa, Measurement range 60 hPa
c. Sample weight: 4 ± 0.01 g
d. Sample (fiber plug) dimensions:
Diameter: 28 mm
