GA-2415 Metallographic Cutting Apparatus

Main Feature:

This machine is suitable for cutting general metallographic samples with irregular cylinder and polygonal shape, so as to observe metallographic and petrographic structures of materials.Adopt double – cover closed structure and door – type safety switch.It can ensure the sample cutting under the condition of absolute safety.This machine has a strong cooling system.The heat generated by cutting can be carried away by using the configured coolant to avoid overheating and burning the tissue.This machine is convenient to use, safe and reliable, it is one of the necessary equipment for making samples in the laboratory of scientific research unit of the factory.



GA-2415 Metallographic Cutting Apparatus

Main parameters:

Max cutting diameter:Φ65mm

Spindle speed:2800r/min

Cutting disc size:Φ250*2*32mm

Power:3phase 380V,50HZ

Input power:1.6KW

Overall size:990*670*1320mm

Net weight:230KG
