GA-2306 Touched Screen Metal Separators
- Description
- Inquiry
Description
Metal Separators
Product features
1，Sensitive response, high detection accuracy
2，Intelligent identification, good stability
3，The error rate is low, basically zero
4，Improve product quality, ensure consumer food safety, reduce unnecessary disputes
Metal Separators
Application field
Food, medicine, aquatic products, toys, clothing, shoes, chemicals, leather, knitting, printing and other industries to detect products or raw materials in the production process mixed with metal impurities.Such as: iron, non-magnetic metal (gold, silver, copper, aluminum, stainless steel and other non-ferrous metals can be detected), improve product safety factor, reduce the harm.
Metal Separators
Specification
| Model | Feed pipe diameter(mm) | Detection sensitivity | Maximum throughput L/h | |
| FeΦ | SUS Φ | |||
| GA-2306-30 | 25 | 0.2mm | 0.5mm | 250 |
| GA-2306-50 | 50 | 0.5mm | 1.0mm | 2000 |
| GA-2306-70 | 70 | 0.7mm | 1.2mm | 5000 |
| GA-2306-100 | 88 | 1.0mm | 1.5mm | 12000 |
| GA-2306-120 | 108 | 1.2mm | 2.0mm | 16000 |
| GA-2306-150 | 138 | 2.0mm | 2.5mm | 25000 |
| GA-2306-200 | 188 | 2.5mm | 3.0mm | 44000 |
| GA-2306-250 | 238 | 3.0mm | 3.5mm | 69000 |
