Description
GA-1611 Ultrasonic Flaw Detector
Introduction
1.Automated calibration、Automated gain
2.DAC、AVG、TCG、B scan、AWS
3.High-speed capture and very low noise
4.Solid metal housing
5.high contrast viewing of the waveform from bright
6.Powerful pc software and reports can be export to excel
GA-1611 Ultrasonic Flaw Detector
Features
1.Automated display precise flaw location(Depth d、level p、distance s、amplitude、sz dB、ф)；
2.Automated switch three staff gauge ((Depth d、level p、distance s)；
3.Automated calibration of transducer Zero-point, Angles, Front edge and material Velocity ；
4.Convenient to make and use DAC\TCG and AVG to evaluate the echo, the curve can be modified and compensated
5.6dB DAC functions;
6.Standards of test for DAC is saved.
7.500 independence setup, any criterion can be input freely, we can work in the scene without test block；
8.Big memory of 1000 A graph
9.Automated gain and gain scan;
10.Peak Hold and Peak Memory；
11.B scan;
12.AWS D1.1
13.Automated make video of test process and play; use USB flash disk，the length of video is unlimited.
14.Powerful pc software and reports can be export to excel;
15.Li battery, continue working time up to 10 hours;
16.The embeded software can be online updated；
GA-1611 Ultrasonic Flaw Detector
Other assistant function
Display freeze;
Automated echo degree;
Angles and K-value;
Lock and unlock function of system parameters;
Electronic clock calendar ;
Two gates setting and alarm indication;
Gate and DAC alarm;
GA-1611 Ultrasonic Flaw Detector
Specifications
| Title | Parameter | Title | Parameter |
| Measuring Range（mm） | 0 ～ 10000 | Measurement Mode | Single、Dual、Thru |
| Vertical Linearity Error | ≤3% | Reject | 0~80% |
| Horizontal Linearity Error | ≤0.1% | Pulse Displacement（μs） | -20 ～ +3400 |
| Sensitivity Leavings | ≥62dB | Zero（μs） | 0.0 ～ 99.99 |
| Dynamic range | ≥34dB | Port Type | BNC / LEMO |
| Resolving Power | ≥36dB | Operating Temperature (℃) | -20～50 |
| Frequency Range（MHz） | 0.5 ～ 15 | H×W×D(mm) | 240×156×50 |
| Gain（dB） | 0 ～ 120 | Weight（kg） | 1.0（with battery） |
| Material Velocity（m/s） | 1000 ～ 15000 |
