GA-1502 Automatic Trace Moisture Tester

Description

GA-1502 Automatic Trace Moisture Tester

Product introduction

The instrument adopts Karl-Fischer Coulomb titration method, which can reliably measure the liquid,

Gas and solid samples for the determination of trace moisture.When tested for insolubility

It can be used in the solid of reagents and substances that are easy to contaminate electrodes and reagents

The corresponding solid, gas and liquid sampler is used for indirect determination, which is a high

Efficient and fully automatic analytical instrument.Widely used in electric power, petroleum, chemical industry,

Medical, railway, environmental protection, scientific research institutions and other industries.



GA-1502 Automatic Trace Moisture Tester

Performance Characteristics

★ High test sensitivity: using Karl-Fischer reagent, Coulomb titration principle test;

Automatic judgment of test end point, buzzing alarm prompt;

★ The dynamic curve of the test process shows the measured potential, the test state is clear, intuitive, clear at a glance;

Automatic display, printing and storage of test data;

Large data storage capacity, can save 1000 analysis and test records;

★ Touch sliding stirring speed regulation, no mechanical contact, simple and reliable;

You can choose 5 kinds of calculation formula.



GA-1502 Automatic Trace Moisture Tester

Specification

Display mode		5 “touch color LCD display	Storage capacity		1000 data records
Status indication		Dynamic curve of measured potential is shown	Print way		Thermal printer
Electrolytic current		400mA	Stirring speed		Panel touch sliding speed regulation
Measure range		0μg～100mgH2O 0～100000ppm	Power		220V±11V 50Hz±2.5Hz
resolution		0.1μgH2O	Rate of power		30W
Accuracy	0μg～100ugH2O No greater than 2μg		Environment humidity	≤85%RH
	>100ugH2ONo greater than ±2%（not include sampling error）		Outside size	335*240*180mm
A formula to calculate	5 kinds of optional		weight	10kg
