TS7600 Grating Spectrophotometer TS7600 Grating Spectrophotometer

Categorie:

Beschrijving

NS810 Portable Spectrophotometer

Gebruik

NS810 portable spectrophotometer uses d/8 structure and comply with CIE No.15, GB/T 3978. With 400~700nm, NS810 features with high accuracy DeltaE*ab 0.04, and 8mm aperture makes measurement so easy. It can save 1000 Normen, 15000 Samples and you also can input your own LAB or XYZ value into the instrument. With SQC8 software, you can do better color control management. Plus, it is widely used in plastic, elektronisch, verf, inkt, textiel, kledingstuk, bedrukken en verven, voedsel, medisch, cosmetisch, industrieën, wetenschappelijke onderzoeksinstituten, scholen en laboratoria.

NS810 Portable Spectrophotometer

Functies:

  1. Display complete reflectance rate and input LAB value manually.
  2. NS810:D/8 structure (diffuse illumination, 8° viewing )
  3. 3.5 inch groot capacitief touchscreen, fully functional touch control.
  4. 2º/10º degree observe, multiple lights, many color systems.
  5. The repeatability ΔE*ab is within 0.04, errors is less than 0.2
  6. Large capacity storage, meer dan 15000 gegevens.
  7. PC software with powerful extension functions.
  8. 15° oblique angle screen, in line with the human eye observation.
  9. Oversized integrating sphere, more effective homogenization ray of lights.
  10. High hardware configuration with a number of innovative technologies.



NS810 Portable Spectrophotometer

Specificatie

Model NS810 Spectrophotometer
Illumination/observation system d/8 (diffused illumination, 8-degree viewing angle) Conforms to CIE No.15, GB/T 3978.
Bolgrootte integreren Φ58mm
Lichtbron Combined LED sources
Sensor Silicium fotodiode-array
Golflengtebereik 400~700 nm
Wavelength pitch 10nm
Reflectiebereik 0~200%
Diafragma meten Φ8mm
Kleurruimte CIE LAB, XYZ, Yxy, LCH, CIE LUV,LABORATORIUM&WI&DOEN
Kleurverschil Formule ΔE*ab,ΔE*uv,ΔE*94,ΔE*cmc(2:1),ΔE*cmc(1:1),ΔE*cmc(l:C),CIE2000ΔE*00,ΔE(H)
Andere kleurkwaliteitsgegevens WI(ASTM E313,CIE/ISO,AATCC, Jager),

DOEN(ASTM D1925,ASTM 313),

Metamerism Index (Mt), Color Strength

Kleur vlek, Kleurechtheid
Waarnemer 2°/10°
Verhelderend D65,D50,A,C,D55,D75,F1,F2,F3,F4,F5,F6,F7,F8,F9,F10,F11,F12
Gegevens weergeven Spectrale waarde/grafiek, Colorimetrische waarde, Color Difference Value/Graph, PASS/FAIL Result, Color Offset, Color Simulation, kleurindex instelling(ΔE*94, ΔE*cmc, ΔE2000), tolerance prompt, reverse prompt, time setting, language setting, restore factory setting
Meettijd 1.5S
Herhaalbaarheid Spectrale reflectie: standaardafwijking binnen 0.1%(400~700 nm: within 0.2%)
Colorimetrische waarde: Standard deviation within DeltaE*ab 0.04 (Meetomstandigheden: witte kalibratieplaat gemeten 30 times at 5 seconds intervals after white calibration was performed.)
Inter Instrument Agreement Within DeltaE*ab 0.2 (Gemiddeld voor 12 BCRA Series II color tiles)
Dimensie L*W*H=90*77*230mm
Gewicht 600G
Batterij Li-ion-batterij. 2800 keer binnen 8 uur.
Levensduur lamp 5 jaar, meer dan 1.6 miljoen metingen
Weergavescherm TFT 3.5inch, Capacitive Touch Screen
Koppel USB/RS-232
Gegevensgeheugen 1000 Normen, 15000 Samples
Operating Temperature 0~40℃(32~104°F)
Storage temperature -20~50℃(-4~122°F)
Standaard accessoire Voedingsadapter, Li-ion-batterij, Operating Instruction, CD-ROM (met beheersoftware), Datalijn, White and Black Calibration Cavity, Protective Cover and Wrist Strap
Optional Accessory Universal Test Components, Micro Printer, Powder Test Box
Notes The specifications are subject to change without notice.



NS810 Portable Spectrophotometer

Toepassingen:

It is widely used in plastic, elektronisch, verf, inkt, textiel, kledingstuk, bedrukken en verven, voedsel, medisch, cosmetic industries, wetenschappelijke onderzoeksinstituten, scholen en laboratoria. Het kan het reflectiespectrum en andere kleurindexen nauwkeurig meten. NS810 spectrophotometer not only can help to perform color matching and color management studies, but also can control product quality management. 3nh colorimeter is equipped with high-end color management software that can connect to PC to achieve more extension functions.
