Penerangan
Ohmmeter
Pengenalan ringkas
AT516/AT516L is brand-new design DC resistance meter with high precision and high stability, which adopts high-performance 32dgt ARM micro processor control. 3.5 inches true-color LCD display screen with Chinese and English menu, and it is easy to operate. AT516/AT516L can be applied to various kinds of resistors, switches contact resistance, connector contact resistance, relay coils and contact resistance, transformers, inductors, motor, deflecting coiling resistance, welding contact conductor resistance, the metal riveting resistance of vehicles, boats, airplanes, printed circuit lines and crack detection and so on.
Ohmmeter
|
SPESIFIKASI |
||||
| AT516 DC Resistance Meter | AT516L DC Resistance Meter | |||
| Parameter |
DC resistance |
|||
| Ketepatan Asas |
0.05% |
0.1% | ||
| Measurement Range | 1mW~20MW | 1mW~30kW | ||
| Measurement Current | I-max:<1A | I-max:<1A | ||
| Julat |
Automatic and Manual with 10 ranges |
7 Automatik atau Manual |
||
| Kelajuan |
140 t/s, 67 t/s,35 t/s,12 t/s, 2 t/s |
12 kali/saat,2 kali/saat |
||
| Paparan |
Show/ΔABS/Δ%/Sorting Results |
|||
| Display Max |
30,000 |
|||
| Pelarasan |
Short-circuit Zero-Adjust for each range. |
|||
| Pembanding |
14 build-in comparators, BIN1-BIN10, HI/IN/LOW display and output, adjustable beep and volume |
1 kumpulan |
||
| Trigger |
Tahap, Dalaman, Manual, External and Remote Trigger |
Dalaman ,Manual, Remote |
||
| Antara muka | RS-232C, Pengendali (PLC interface), antara muka USB | RS-232C interface, antara muka USB | ||
| Test Lead | 4 terminal shielding (2 check terminal and 2 driving terminal) and external shielding ground section | |||
| Temperature compensation | Ketepatan: 0.2 °C
Julat: 0~80 °C |
|||
| Lain-lain | True-color TFT-LCD display
Keypad locks function; Data Hold function; Chinese and English menu |
|||
|
CIRI-CIRI UMUM |
||||
| Bekalan kuasa |
voltan: 198VAC~240VAC, Kekerapan: 50/60Hz; Max Power: 15VA. Pilihan: 110VAC |
|||
| Saiz |
Outside (mm):264 (lebar)x107(ketinggian)x350 (kedalaman) Inside (mm):216(lebar)x88(ketinggian)x323(kedalaman), 4kg |
|||
| ORDER ING INFORMATION | ||||
| Accessory | ATL501A Kelvin clip; ATL108: 232 communication cable; temperature compensation probe; Kord kuasa AC | |||
| Pilihan | ATL620 Meter Resistance Four-terminal Clamp Fixture | |||
