설명
NS810 휴대용 분광 광도계
사용
NS810 portable spectrophotometer uses d/8 structure and comply with CIE No.15, GB/T 3978. With 400~700nm, NS810 features with high accuracy DeltaE*ab 0.04, and 8mm aperture makes measurement so easy. It can save 1000 표준, 15000 Samples and you also can input your own LAB or XYZ value into the instrument. 와 함께 SQC8 software, you can do better color control management. Plus, it is widely used in plastic, 전자, 페인트, 잉크, 직물, garment, printing and dyeing, 음식, medical, cosmetic, industries, scientific research institutes, schools and laboratories.
NS810 휴대용 분광 광도계
특징:
- Display complete reflectance rate and input LAB value manually.
- NS810:D/8 structure (diffuse illumination, 8° 보기 )
- 3.5 inch large capacitive touch screen, fully functional touch control.
- 2º/10º degree observe, multiple lights, many color systems.
- The repeatability ΔE*ab is within 0.04, errors is less than 0.2
- Large capacity storage, 이상 15000 데이터.
- PC software with powerful extension functions.
- 15° oblique angle screen, in line with the human eye observation.
- Oversized integrating sphere, more effective homogenization ray of lights.
- High hardware configuration with a number of innovative technologies.
NS810 휴대용 분광 광도계
사양
| 모델 | NS810 Spectrophotometer |
| Illumination/observation system | d/8 (확산 조명, 8-정도 시야각) Conforms to CIE No.15, GB/T 3978. |
| Integrating sphere Size | Φ58mm |
| 광원 | Combined LED sources |
| 감지기 | 실리콘 포토다이오드 어레이 |
| 파장 범위 | 400~700nm |
| Wavelength pitch | 10nm |
| Reflectance range | 0~200% |
| 조리개 측정 | Φ8mm |
| 색 공간 | CIE 연구소, XYZ, 와이시, LCh, 씨에 러브,LAB&위스콘신&~하다 |
| Color difference Formula | ΔE*ab,ΔE*uv,ΔE*94,ΔE*cmc(2:1),ΔE*cmc(1:1),ΔE*cmc(l:씨),CIE2000ΔE*00,ΔE(h) |
| Other Chromaticity Data | 위스콘신(ASTM E313,CIE/ISO,AATCC, 사냥꾼),
~하다(ASTM D1925,ASTM 313), Metamerism Index (Mt), 색상 강도 Color Stain, 색상 견뢰도 |
| 관찰자 | 2°/10° |
| 조명 | D65,D50,A,씨,D55,D75,F1,F2,F3,F4,F5,F6,F7,F8,F9,F10,F11,F12 |
| Display Data | Spectral Value/Graph, Colorimetric Value, Color Difference Value/Graph, 합격/불합격 결과, 색상 오프셋, Color Simulation, color index setting(ΔE*94, ΔE*cmc, ΔE2000), tolerance prompt, reverse prompt, time setting, language setting, restore factory setting |
| 측정시간 | 1.5에스 |
| 반복성 | Spectral Reflectance: standard deviation within 0.1%(400~700nm: 이내에 0.2%) Colorimetric Value: Standard deviation within DeltaE*ab 0.04 (Measurement conditions: white calibration plate measured 30 시간 5 seconds intervals after white calibration was performed.) |
| Inter Instrument Agreement | Within DeltaE*ab 0.2 (평균 12 BCRA 시리즈 II 컬러 타일) |
| 치수 | L*W*H=90*77*230mm |
| 무게 | 600g |
| 배터리 | Li-ion battery. 2800 times within 8 시간. |
| 램프 수명 | 5 연령, 이상 1.6 백만 측정 |
| Display Screen | TFT 3.5inch, 용량 성 터치 스크린 |
| 상호 작용 | USB/RS-232 |
| Data Memory | 1000 표준, 15000 Samples |
| Operating Temperature | 0~40℃(32~104°F) |
| Storage temperature | -20~50℃(-4~122°F) |
| 표준 액세서리 | 전원 어댑터, Li-ion Battery, Operating Instruction, CD-ROM (containing management software), Data Line, 흰색 및 검정색 교정 캐비티, Protective Cover and Wrist Strap |
| 옵션 액세서리 | Universal Test Components, 마이크로 프린터, 분말 테스트 박스 |
| 노트 | 사양은 예고 없이 변경될 수 있습니다.. |
NS810 휴대용 분광 광도계
응용:
It is widely used in plastic, 전자, 페인트, 잉크, 직물, garment, printing and dyeing, 음식, medical, cosmetic industries, scientific research institutes, schools and laboratories. It can measure reflectance spectrum and other color index precisely. NS810 spectrophotometer not only can help to perform color matching and color management studies, but also can control product quality management. 3nh colorimeter is equipped with high-end color management software that can connect to PC to achieve more extension functions.
