Registratore di dati di temperatura Anbai AT4508A
- Descrizione
- Inchiesta
Descrizione
Temperature Data Recorder
Brief introduction
AT45xxA series multi-channel temperature meter adopt high-performance ARM micro processor, can collect multi-channel temperature data simultaneously and response quickly. AT45xxA series have the function of high/low beep function and communication transmission. 48 channels’ temperature data can be extended, compatible with various temperature sensors. Support RS-232 communication, realize data acquisition, analysis and print through the standard computer software. Has USB disk storage and store real-time sampling data. The users can adjust data for each channel independently.
Temperature Data Recorder
|
SPECIFICHE |
|||
|
AT4508A |
AT4516A/ AT4524A |
AT4532A |
|
| Graduation |
Termocoppia: J/K/T/E/S/N/B/R, Thermal resistance: PT100/CU50 |
||
| Precisione di base | Termocoppia: 0.2℃ ± 2 cifre (not include thermocouple accuracy)
Thermal resistance: ±0.6 (not include thermal resistance accuracy) |
||
| Measurement Allineare | -200°C~1300°C(Varying depend on graduation) | ||
| Risoluzione | Termocoppia: 0.1℃; Thermal resistance: 0.01℃ | ||
| Canali | 8 canali;
Can be expanded to 48 canali |
16/24 canali;
Can be expanded to 48 canali |
32 canali;
Can be expanded to 48 canali |
| Velocità |
Fast: 100ms/channel Medium: 500ms/channel Slow: 1s/channel |
||
| Correction |
Error correction for each channel |
||
| Comparatore | High/low beep. Individual setting high/low value for each channel | ||
| Interfaccia | RS232C interface, U-disc interface | ||
| Opzioni | Mini printer interface | ||
| Software | ATS45xx data acquisition software | ||
| Cold Junction
Compensation |
Precisione:0.5℃ | ||
| Altri | TFT-LCD True-color LCD display,broken thermocouple check function | ||
| CARATTERISTICHE GENERALI | |||
| Alimentazione elettrica | Voltaggio:85VAC~260VAC Frequency:50Hz/60Hz Power:10VA | ||
| Misurare | 216mm(Larghezza)x88mm(Altezza)x300mm(Profondità), 3kg | ||
| INFORMAZIONI PER L'ORDINAZIONE | |||
| Accessori | AT4508A: K thermocouple 8 teams(2m/team)
AT4516A/AT4524A: K thermocouple 16/24 teams(2m/team) AT4532A: K thermocouple 32 teams(2m/team) Opzionale: PT100/CU50 thermal resistance RS232 communication cable, USB data cable, USB convert box, PC software, AC power cord |
||
