Keterangan
Detektor Kebocoran Udara GA-2805
Menggunakan
GA-2805 Air-tightness adopts differential pressure principle and uses compressed air as the medium for product detection. It is a non-destructive testing instrument.With its high precision, complete function and other characteristics, it is widely used in the sealing testing of product parts.
Detektor Kebocoran Udara GA-2805
Functional features
32 bit processor and 12 bit A/D converter
Alarm function of two stages: big leak and small leak
Zero leakage air leakage control valve set
Display the leakage unit pa, ml/min
Keluaran, OKE,Dari, counting function
7 Layar sentuh inci, Chinese and English interface
Historical data records, usb output
External I/O interface, kontrol 2 sets of clamped cylinders
Detektor Kebocoran Udara GA-2805
Bidang aplikasi
Automobile industry: suku cadang mobil, waterproof test of auto lights, car camera, engine parts, automobile water tank, fuel tank, box cover, transmission box, oil road, pipeline, dll.
Home appliance industry: electric iron, humidifier, aromatherapy machine, coffee machine, kettle, juicer, sweeper, gas stove, water heater, dll.
Electronic digital industry: bracelet, waterproof watch, waterproof sound box, three – defense mobile phone, bluetooth audio, interphone, shaver, electric toothbrush, all kinds of electronic components
Valve fitting: sealing test of joints, katup, corrugated pipes and pump body
Detektor Kebocoran Udara GA-2805
Spesifikasi teknis
| Model | GA-2805(Middle pressure) | GA-2805(High pressure) | |
| Testing pressure range | 1Kpa~700kpa | 0.3Mpa~3.5Mpa | |
| Test pressure display accuracy | 1Kpa | 0.01MPa | |
| Differential pressure transducer | Rentang tampilan:-2000pa-2000pa | Rentang tampilan:-2000pa-2000pa | |
| Resolusi :1pa | Resolusi :1pa | ||
| I/O interface | 7 input singals | 7 output singals | |
| Test volume | The volume of the test product is less than 10 liters.The smaller the volume, the faster the test speed | ||
| Historical data | Historical data record display, support usb drive export Excel file | ||
| Test time | Prepare1–prepare2–pressurized–balance–detection–exhaust–remove
Jangkauan:0.1s~~999.0s |
||
| Ukuran | D500*W250*H330(mm) | ||
| Berat | About 12KG | ||
| Kekuatan | AC 220V±10%,50/60HZ,Consumption of electricity:50VA | ||
| Test pressure source | Dry clean air source with high flow and stable pressure | ||
| Ambient temperature and humidity | Use of temperature:5~40℃,storage temperature -20℃~70℃,below 80%RH,But no condensation | ||
