Descripción
Heating Tablet Press Machine
Campo de aplicación
We are specialized in the production of powder tablet press and mold manufacturers. Our tablet press is small in size, high in pressure, high in pressure control precision, and has been used in scientific research, teaching, pruebas, farmacéutico, catalysis, chemical industry and other industries. Además, this product can also be used with Fourier infrared optical spectrometer, burning light spectrometer and other test instruments supporting sample preparation, and can replace similar imported products.
Scientific research
Electronics industry
Pharmaceutical and chemical industry
Battery energy
Catalytic reaction
Jewel diamond
Ceramic material
Cement ore
Heating Tablet Press Machine
| Pressure range | 0-24t(0-34MPa) |
| Piston diameter | Chrome plated cylinder in 95mm |
| Overall structure | The equipment has no sealed connection to reduce oil leakage points |
| The thermostat controls the temperature | Room temperature -600.0°C |
| Die heating temperature | Room temperature -500.0°C |
| Precisión del control de temperatura | 0.1 C |
| Heat insulation method | Imported heat insulation board + water cooling heat insulation board [Water cooling machine standard) |
| Cooling method | Water cooling rapid cooling [Water cooler selection] |
| Die size | Double plate heating 100X100mm (MXN) |
| Main engine size | 245X175X500mm (KXPXH) |
| Tamaño global | 1000X470X500mm (LXWXH) |
| Fuente de alimentación | 220V/3000W |
| Main engine weight | 58Kg |
