TH2883S8-5 Impulsspulentester

Beschreibung

Pulse Coil Tester

Independent channel control, simple and intuitive operation Embedded online help system and screen saver function Humanized design of the arc knob with the press to zero function Wave brightness, grid brightness adjustable function Pop-up menu display mode, the user is more flexible, natural * a rich key operation: a key storage, a key to restore the factory settings, a key print and a single key capture Support U disk and local memory file storage 2 sets of reference waveforms, 20 sets of settings, 10 sets of waveform internal storage Hardware frequency counter display
Analog channel bandwidth: 50MHz, 70MHz, 100MHz, 150MHz Real time sampling rate up to 50GSa/s, equivalent sampling rate of 50GSa/s equivalent sampling rate of 1GSa/s Max storage depth 2Mpts 5 trigger types: edge, pulse width, video, slope, alternation 5 kinds of mathematical operations: +, -, *,/, FFT Unique digital filtering and Waveform Recorder Waveform recording and Pass/Fail detection Standard configuration interface: Host USB: support U disk storage and firmware upgrade; Device USB: support PC remote control and PictBridge printing; RS232, LAN and Pass/Fail; optional USB-GPIB SDS1000A series is a universal dual channel digital oscilloscope products, with 50MHz, 70MHz, 100MHz and 150 MHz bandwidth models;Up to 2Mpts of storage depth, in the capture of long signal at the same time, to ensure the fine waveform resolution; equipped with 7 inch color TFT-LC (800*480) LCD screen, help you better insight into the details of signal sampling rate; 1GSa/s allows you to easily inspect the instantaneous signal; simple interface to ensure the usability of the oscilloscope; 32 parameter automatic measurement and the usual arithmetic functions, greatly enhance the work efficiency, easy to deal with the complex requirement of measuring signal.

Pulse Coil Tester
