GA-8855 Tisch-Röntgenfluoreszenzspektrometer

1.7. Produktmerkmale
1.7.1 GA-8855 is equipped with a vacuum test system to increase the element test range. The detector is equipped with a test system of SDD to detect the elements in the ore room and reduce the interference between elements
1.7.2 the overall structural design makes the instrument beautiful and elegant.
1.7.3 it adopts the latest silicon drift detector in the United States, electric refrigeration instead of liquid nitrogen
refrigeration, with small volume, accurate data analysis and low maintenance cost.
1.7.4 self developed SES signal processing system (digital multi-channel) is adopted to effectively improve the peak to back ratio and make the measurement more accurate.
1.7.5 one click automatic test makes it easier to use, more convenient and more user-friendly.
1.7.6 seven kinds of optical path correction and collimation systems are automatically switched according to different samples.
1.7.7 multiple anti radiation leakage design, radiation protection level belongs to the highest level of similar products.
1.7.8 optimize the integrated heat dissipation design to greatly improve the heat dissipation performance of the whole machine and ensure the operation safety of X-ray source.
1.7.9 the unique movement temperature monitoring technology ensures the safe and reliable operation of the radiation source, effectively prolongs its service life and reduces the use cost.
1.7.10 multiple instrument accessories protection system, and the whole process monitoring can be carried out through software, making the instrument work more stable and safer.
1.7.11 special vacuum test software, whether vacuum can be freely selected, vacuum degree can be displayed in real time, standard window design, benutzerfreundliche Oberfläche, easy operation, all control are between the mouse.
1.7.12 the USB2.0 interface is adopted to ensure the accurate, high-speed and effective data transmission.
1.7.13 the unique automatic vacuum system can completely shield the influence of air on light element test, greatly improve the detection limit of light element, and expand the detection range.
1.7.14 the integrated vacuum chamber design effectively ensures the vacuum degree meeting the test requirements and improves the maintainability of the equipment.
1.7.15 it is easy to switch between vacuumizing test and non vacuumizing test, which is convenient for customers to use; Gleichzeitig, the vacuum can be removed by opening the cover, which is safe, simple and practical.

analysis range of element content	1ppm bis 99.99%;
Messzeit	100-300 Sekunden (einstellbar)
The detection limit of harmful elements (CD / Pb / Cr / Hg / BR / CL) specified in ROHS directive	up to 1ppm
energy resolution	129 ± 5 EV
Stromversorgung	Wechselstrom 220 V ± 5V (AC purified regulated power supply is recommended)
Temperaturbereich	15 ℃ to 30 ℃

X-ray Fluorescence Spectrometer

Arbeitsbedingungen

Arbeitstemperatur	15-30 ℃
Relative Luftfeuchtigkeit	40% ～ 70%
Stromversorgung	Wechselstrom: 220 V ± 5V
