Packaging Breaking Force Tester
4

GA-5055 Packaging Breaking Force Tester

Bottle Wall Thickness Gauge GA-5054 Electronic Bottle Wall Thickness Gauge
GA-5056 LCD Control Box Compression Tester

Kategorie:

Beskrywing

Packaging Breaking Force Tester

Test Standard

GB2637, YBB00332002 standard on the breaking force test of ampoule drug packaging requirements

Produk Karakter

  • Large liquid crystal display test process, PVC operation panel, humanized design
  • Professional software can connect computer to save, analyze and print data
  • Imported sensors are used to ensure the accuracy of test results
  • Compact, compact and humanized structure design
  • The speed of the lead screw drive system is adjusted at will to ensure the accuracy of test speed and displacement
  • Equipped with a micro printer to quickly print test results
  • Professional and humanized fixture can be replaced arbitrarily for different size samples
  • Intelligent configuration, such as limit protection and automatic return, ensures user’s operation safety

Packaging Breaking Force Tester

Test Principle

The sample was clamped between two clamps, and the two clamps made relative movement. The ampoule bottleneck was separated from the flat body through the special clamps. The force change and displacement change during this process were tested by the instrument, and the corresponding force value data was obtained.

Basic Application

It is suitable for testing breaking force in ampoules, lipstick and lipstick.

Packaging Breaking Force Tester

Technical Specification

Item Spesifikasie
Toetsreeks 0-500 N（can choose 100N、200N、300N）
Test Accuray 0.5vlak
Test speed 10 mm/min（1-500 mm/minstepless speed change）
Speed accuracy ±2% error
Support distance 36mm、60mm
Out size 330 mm (L) × 410 mm (W) × 680 mm (H)
Krag AC 220V 50Hz
New weight 27 kg

Packaging Breaking Force Tester
